RJ45 cable carrier consisting of shell, fixing disk, chuck, bush and
boot. Packed with two cable protection elements for cable diameter
either up to 5 mm or 8 mm. For preassembled RJ45 plugs. Standard bushing
color is black, 9 different coding colors available.
Specs depend on type of RJ45 plugs used.
Cable O.D. range: max. 8 mm / 0.315"
Life time: > 1000 mating cycles
Housing: ZnAl4Cu1, gal Ni
Strain relief clamp: POM
Bushing: PA 6 15% GR
Boot: PA 6
Temperature range: -30°C to +80°C
|RJ45 Data Connector / EtherCon® Series
The EtherCon® Series offer both male cable carriers and assembled
female receptacles. The cable end offers a robust die-cast shell as
a carrier for pre-assembled and not assembled RJ45 plugs. Female chassis
connectors are based on the current NEUTRIK® #A & B# Series as
well the #D# Series of XLR receptacles with secure latching system
- a feature not found on other RJ45 receptacles. Terminations are
horizontal and vertical PCB or IDC, punch down. Color coding is available
for both the cable carrier and the receptacles for ease of identification.
NEUTRIK® EtherCon® products comply with Category 5 (IDC versions)
shielded or unshielded and are compatible for use with 10 Base-T and
100 Base-TX systems.
